High-efficiency hydrocyclone is a kind of classification equipment which uses centrifugal force to accelerate the sedimentation of ore particles, and is widely used in mining, chemical industry, water treatment and other industries.
Product Features & Benefits
High Efficiency: Classification efficiency can reach 80%~90%, especially for fine-grained materials (< 0.1mm).
Simple Structure: Composed of a hollow cylinder and a cone without complicated transmission parts, ensuring convenient maintenance.
Compact Design: Small floor space requirement helps in saving land resources.
Strong Adaptability: Adapts to changes in pulp properties such as particle size, density, and concentration.
Wear Resistance: Built with cemented carbide or silicon carbide in high-wear areas like the grit and feed ports.
Principle of Operation
The working principle is based on centrifugal force. When pulp enters the cyclone shell tangentially under pressure, it rotates at high speed. Coarse or dense particles are pushed to the periphery by centrifugal force and flow downward along the wall to be discharged from the bottom grit port. Fine or low-density particles move toward the center and upward, discharging through the overflow pipe.
Technical Parameters
Model
Inner Diameter (mm)
Max Feeding Strength (mm)
Inlet Pressure (MPa)
Capacity (m³/h)
Separation Size (mm)
100
100
1
0.05 - 0.4
1 - 12
10 - 100
125
125
1
8 - 15
20 - 100
150
150
1.5
11 - 20
30 - 74
200
200
2
25 - 40
30 - 100
250
250
3
40 - 65
40 - 100
300
300
5
45 - 90
40 - 150
350
350
6
0.03 - 0.4
60 - 105
50 - 150
Product Display & Gallery
Packaging & Shipping
Field Case Presentation
Frequently Asked Questions
What is the classification efficiency of this hydrocyclone?
The high-efficiency hydrocyclone can achieve a classification efficiency of 80% to 90%, making it particularly effective for fine-grained materials smaller than 0.1mm.
What materials are used for wear-prone parts?
Parts subject to high wear, such as the grit port and feed port, are manufactured using wear-resistant materials like cemented carbide or silicon carbide to prolong service life.
In which industries is this equipment primarily used?
It is widely used for classification and dewatering in mining, coal washing plants, chemical processing, and sandstone aggregate production.
What kind of after-sales service is provided?
We provide comprehensive after-sales service and support for all our equipment, with a standard warranty period of 1 year.
Can the equipment handle different pulp concentrations?
Yes, the system features strong adaptability and can adjust to changes in pulp properties, including varying density, particle size, and concentration.
What are the main components of the hydrocyclone?
The equipment features a simple and robust structure primarily consisting of a hollow cylinder and a cone, which simplifies both manufacturing and maintenance.
