Main business focus includes industrial ceramics, refractory materials, corundum wear-resistant ceramics, papermaking equipment and accessories, pulping equipment and accessories, dewatering equipment, slag removal equipment, wear-resistant pipes, alumina ceramic parts, thermocouple protection tubes, and electronic insulation materials.
Customer Focus: Quality first and customer satisfaction is our unremitting pursuit. We handle the technical requirements to ensure excellence in every project.
Thickness
3~50mm or Request
Content
92%, 95% Alumina, T95, ZTA
Density
3.6 - 5.9 g/cm³
Compressive Strength
> 1050 MPa
MOQ
1 Ton
Samples
Free Samples Available
Delivery Time
25-40 Days
Payment
T/T or L/C
Technical Specifications (99% Alumina)
Al2O3 Content
≥ 99%
Volume Density
≥3.80 g/cm³
Max Temperature
1800ºC
Bending Resistance
>350 Mpa
Compressive Strength
>12000 Mpa
Usage
Thermocouple protection, Heat treatment furnaces, Electric furnace heating tubes
Transport and Installation Precautions
Avoid serious collision during transportation to protect the ceramic layer.
Follow the direction indicated by the arrow for bending pipe installation.
Align pipes with the center line; displacement should be within 1.0mm.
For flexible joints, adjust inserted lengths symmetrically to account for thermal expansion.
Welding is possible with a 45°-60° "V" type slope angle.
Frequently Asked Questions
Q: Are you a trading company or a manufacturer?
A: We are a factory and professional manufacturer of industrial ceramics.
Q: How long is your delivery time?
A: Generally 15 days if mould sizes are in stock; 25 days if customized, depending on order quantity.
Q: Do you provide free samples?
A: Yes, we offer stock samples for free, although the cost of freight is not included.
Q: What are your terms of payment?
A: For new customers, 100% T/T in advance. For regular customers, 30% T/T in advance and the balance after receiving the B/L copy.
Q: Can the ceramic parts be customized?
A: Yes, all our products including dimensions and alumina content (92%, 95%, 99%) can be customized to your specific request.
Q: What is the maximum length of the ceramic tubes?
A: Our 99% alumina ceramic tubes can reach a maximum length of 2000mm.
