Advanced Wear-Resistant High Alumina Ceramic Lining Tiles provide long-lasting solutions to the problems caused by abrasive wear and corrosion in a variety of hostile environments. Alumina ceramic linings will outlast lower grade materials commonly used to line or protect processing and material handling equipment, including Basalt, stainless steel, carbon steel and wear resistant plates, by factors of 3 to 15 times.
Our wear resistant ceramic tiles can be cut into any shape and are easy to install and maintain. They are suitable for both wet and dry processing applications, combining high strength and toughness with extreme hardness.
Ceramic Wear Lining Types:
Key Features:
| Character | 92 | 95 | T95 | 99 | ZTA |
|---|---|---|---|---|---|
| Density(g/cm³) | ≥3.6 | ≥3.65 | ≥3.7 | ≥3.83 | ≥4.15 |
| Al2O3(%) | ≥92% | ≥95% | ≥95% | ≥99% | ≥75% |
| Bending Strength(MPa) | ≥220 | ≥250 | ≥300 | ≥330 | ≥400 |
| Compressive Strength (MPa) | ≥1050 | ≥1300 | ≥1600 | ≥1800 | ≥2000 |
| Vickers Hardness (MPa) | ≥950 | ≥1000 | ≥1100 | ≥1200 | ≥1400 |
| Wear Volume(cm³) | ≤0.25 | ≤0.20 | ≤0.15 | ≤0.10 | ≤0.05 |
Over 25 years of experience in wear solution products with ISO9001:2015 certification. Our factory spans 50,000 sqm with advanced production lines.
